This trio of high-performance CANbus keyboards—PKI, PKD, and PKR—bring compact design, high configurability, and reliable tactile feedback into one seamless solution, redefining how operators interact with their machine environments.
3 series of rugged keypads for centralized control
PKI series – The modular version
Offering flexible layouts (2–15 keys) and removable icon inserts, the PKI series supports rapid customization for any application. Available in 15mm or 24mm button sizes, it ensures precise control—even when wearing gloves. The keypad delivers clear tactile feedback and configurable RGB LED rings for status indication, all within a compact, sealed design.
Key Benefits:
- Replaceable laser-etched icon inserts
- RGB LED rings and icons
- Easy reconfiguration
- CANopen and J1939 support
- IP67/IP69K protection for outdoor use
Download user manual, CAD files and datasheet on the product page
PKD series – The versatile option
The PKD series combines three essential control functions—joystick, rotary encoder, and pushbutton—into a single, space-saving knob. With CANopen and J1939 protocols embedded, this unit simplifies user interaction with touchscreen or display interfaces while maintaining operational safety and comfort. Designed for intuitive operation, the PKD reduces training time and streamlines access to multiple machine functions.
Key Benefits:
- Ergonomic all-in-one design
- Customizable LED ring (8 segments)
- Waterproof and UV resistant (IP67/IP69K)
- Easy vertical, horizontal, or symmetrical mounting
- Up to 3 million operations
Download user manual, CAD files and datasheet on the product page
PKR series – The ultra-compact model
Designed for harsh conditions, the PKR keypad offers a soft-touch rubber overlay with precise tactile response and enhanced grip. Despite its ultra-compact form factor, it supports dynamic multi-color LED feedback, customizable laser-etched icons, and up to 3 RGB indicators per button—ideal for multi-function control in tight spaces.
Key Benefits:
- Ultra-compact and glove-friendly
- High-density button layout
- LED icons and points (0 to 3 per key)
- Superior shock, vibration, and UV resistance
Download user manual, CAD files and datasheet on the product page
YOUR GUIDE TO SELECT THE RIGHT KEYPAD
| Feature | PKI series | PKD series | PKR series |
|---|---|---|---|
| Function Type | Keypad with removable icons | 3-in-one jog dial with pushbutton + encoder + joystick | Compact rubber keypad |
| Customization Options | Inserts, layout, LED | Knob shape, LED, logo | LED, icon, layout |
| Protocols | CANopen, J1939 | CANopen, J1939 | CANopen, J1939 |
| Illumination | RGB rings & icons | 8-segment LED ring | RGB icons & up to 3 LED points/key |
| Lifespan | 3 million operations | 3 million operations | 3 million operations |
| Ingress Protection | IP67/IP69K | IP67/IP69K | IP67/IP69K |
| UV Resistance | UVB 400 hrs | UVB 400 hrs | UVB 400 hrs |
| Operating Temp Range | -40°C to +70°C | -40°C to +70°C | -40°C to +70°C |
| MTBF (hours) | 122,294 | 239,870 | 239,870 |
WHY OPT FOR THESE CAN BUS KEYPADS?
Embedded
CANopen & J1939 protocols
Configurable via user manual for seamless system compatibility.
Full customization
Customize icons, LED colors, knob shapes, layouts, and engravings. Flexible design adapts to your machine and user needs.
High sealing level and UV-resistant
Built to endure harsh environments with IP67/IP69K sealing and UVB 400h protection for reliable outdoor use.
APPLICATIONS ACROSS VEHICLES and MACHINERY
The PK range is tailored for high-demanding HMI applications, including:
Excavator and construction vehicles
MEWPs and material handling equipment
Military and defense vehicles
Agriculture machinery
Electric transport (e-buses, EVs…)
Industrial automation
DISCOVER THE NEW CANBUS KEYBOARDS WITH OUR SPECIALISTS
Whether you need a multifunction knob, a customizable keypad, or a compact control interface, APEM’s PK range offers a tailored solution for every vehicle environment.
Get in touch with our HMI specialists to discuss your project and request a live demo.
